RayTemp 28 High Temperature Infrared Thermometer

Buyer Rating: 5 out of 5 from 3 Reviews

814-028 New ETI

RayTemp® 28 High Temperature Infrared Thermometer

  • auto-power off, display hold & backlight functions
  • wide temperature range -50 to 1370 °C
  • robust IP54 housing for durability
  • dual laser for precise targeting
  • external type K probes extra

More details

in stock

£130.00 ex VAT

£156.00 inc VAT

The RayTemp 28 is a professional infrared, non-contact thermometer with dual laser dot alignment. The thermometer incorporates a 30:1 optic ratio (target distance/diameter ratio), which enables users to measure small targets from a distance or any item that is difficult to reach.

The thermometer features a three-button keypad, allowing the user to select the mode required, i.e. max, min, differential or average temperatures, view the max/min and configurable high/low alarms. Adjustable emissivity allows the user to measure a variety of surface types.

The RayTemp 28 has a clear, easy to read, custom LCD display that features a backlight for when ambient light levels are low and an auto-power off facility that turns the instrument off after 35 seconds, maximising battery life. Each unit is housed in a robust IP54 splashproof case to help reduce the possibility of damage in harsh environments and is supplied in a protective ABS carrying case.

two instuments in one:
The RayTemp 28 incorporates a miniature thermocouple type K probe socket that enables a wide range of type K thermocouple probes to be used for a variety of temperature measurement applications, including air, liquid and surface temperatures. No probes are included to enable the user to select those most suited the their application

To add recommended probes and other accessories select your choices from the 'Add Accessories' dropdowns, then click 'Buy Now! button.

For details of more compatible type K thermocouple probes click here.

Click here to read our infrared thermometer guide!

Click here for some useful infrared thermometer tips.

range - infrared: -50 to 1350°C
range - probe: -50 to 1370°C
resolution: 0.1°C to 1000°C thereafter 1°C
accuracy - infrared: ±2 °C or ±2 % of reading whichever is greater (0 to 1350 °C) otherwise ±4 °C or ±4 % of reading whichever is greater
accuracy - probe : ±1 °C or ±1 % of reading whichever is greater
field of view: target ratio 30:1
emissivity: 0.95 default - adjustable 0.1 to 1.00
battery: 9 volt PP3 alkaline
battery life: 40 hours continuous use
display: custom LCD
backlight: Yes
dimensions: 83 x 95 x 192mm
weight: 275 grams
case material: ABS plastic
water/dust resistance: IP54 protection
measurement scale: Celsius/Fahrenheit

ThermaData Studio v3.1.0 (Windows 10)

ThermaData Studio v3.1.0 (Windows 7 & 8)

ThermaData Studio software for real-time data collection, graphing, statistical analysis, and exporting data in user friendly dashboard style directly to the PC. Available for free download. Single software suite works with ThermaData LoggersUSB Probes and BlueTherm Probes

Works with:

  • ThermaData Series I
  • ThermaData Series II
  • ThermaData Series RF
  • ThermaData Series SST
  • ThermaData Series Thermocouple
  • BlueTherm Probe/IR/Duo
  • ThermaData Series USB Temperature Probes

View the data you want to see, when you want to see it. Customise the ThermaData Studio dashboard view with real-time trend graphs, table views of recorded readings, statistical analysis, current temperature displays, summary data view and more. Import a map of your facility and with ThermaData RF Wireless and BlueTherm Loggers you can add each device in the map view. See exactly where every alarm condition is located.

ThermaData Studio Software

ThermaData Studio allows the connection of up to 16 RF Wireless Loggers and an unlimited number of ThermaData Series I & II Loggers.

Eliminate the need for multiple software systems with the ThermaData Logger software package. With only one software system, training, setup, download and temperature monitoring is easy.

  • Single software system works with over 40 different logging devices
  • User friendly Dashboard design
  • Allows real-time data acquisition (for compatible devices)
  • Graphing/trending chart with up to 32 traces
  • Statistical and table view
  • SMS alarm condition alerts
  • Import facility map for identifying logger by physical location
  • Combine and preview data from multiple loggers and files




RayTemp 28 instructions

Instructions for the ETI RayTemp 28 infrared thermometer

Download (485.29k)

814-028 C of C

814-028 RayTemp 28 certificate of conformity

Download (133.81k)
